Tank Bottom Sampling Ball Valve1. Manufacturing scopeSize : Class 150 : DN25*40 (1"*1-1/2") ~ DN150*200 (6"*8")Class 300 : DN100*150 (4"*6") ~ DN150*200 (6"*8")...
| Quantity: | |
|---|---|
Three-piece flange ball valves and gate valves are both types of valves; however, they differ in that the former's closure element is a sphere that rotates around the centerline of the valve body to open and close. Ball valves are primarily used in pipelines to cut off, distribute, and change the direction of medium flow.
● Reasonable Design: The compact structure effectively reduces the installation space, allowing the valve to be flexibly applied to various pipeline systems.
● Corrosion Resistance: This valve is constructed from high-quality materials and exhibits excellent wear resistance, thereby extending its service life.
| 1 | CAP | SS304/SS316/A105 | 9 | THRUST WASHER | PTFE |
| 2 | BOLT WASHER | SS304/SS | 10 | PACKING | PTFE |
| 3 | HEX NUT | SS304/SS | 11 | GLAND | SS304/SS |
| 4 | BOLT | SS304/SS | 12 | LOCATING PIECE | SS304/SS |
| 5 | BODY | SS304/SS316/A105 | 13 | HANDLE | SS304/SS |
| 6 | SEAT | PTFE | 14 | STEM NUT | SS304/SS |
| 7 | BALL | SS316/SS304/SS | 15 | PLASTIC COVER | PLASTIC |
| 8 | STEM | SS316/SS304/SS | 16 | DOWEL | SS304/SS |
Main Dimensions
| DN | G | DN | D | L | W | H |
| 15 | 1/2" | 14 | 35 | 92 | 120 | 70 |
| 20 | 3/4" | 20 | 40 | 111 | 120 | 80 |
| 25 | 1" | 23 | 50 | 127 | 130 | 90 |
| 32 | 11/4" | 32 | 60 | 140 | 160 | 110 |
| 40 | 11/2" | 38 | 65 | 152 | 160 | 120 |
| 50 | 2" | 49 | 78 | 158 | 280 | 130 |
| Nominal Size | 1/2"-4" |
| Nominal pressure | 1.6Mpa-25Mpa |
| Temperature | -20ºC~220ºC |
| Medium | water, oil, gas and some corrosive mediun |
| Connection type | Flange, butt welded, threaded |
| Operation | manual, electric, pneumatic |
Product Display
Q1:What is the benefit of the floating ball design?
The floating ball design allows for smooth, efficient flow control as the ball moves with the flow of the fluid, ensuring minimal resistance and optimal performance.
Q2:What is the valve's temperature and pressure range?
The valve can handle temperatures from -40ºC to 300ºC (hard seal) or -40ºC to 180ºC (soft seal) and is rated for nominal pressures from PN1.6 to 6.4 MPa.
Our three-piece ball valve is crafted from high-quality materials, ensuring the product's durability and reliability. Its unique design streamlines installation and maintenance, significantly enhancing work efficiency. Ball valves boast exceptional sealing performance, effectively preventing leaks and ensuring the safe and stable operation of the system. Lastly, we offer comprehensive after-sales service to guarantee that customers receive timely technical support and solutions during their use.
