The ball in the Q74F wafer three-way ball valve is driven by the valve stem and rotates around the valve shaft. This valve is not only used for fluid regulation and control but also features a hard-sealed V-shaped ball core and a metal seat with a hard alloy surface, which provides strong shear force, making it particularly suitable for media containing fibers and tiny solid particles. The multi-port ball valve can flexibly control the convergence, diversion, and direction of flow of the medium, and it can also close any channel and connect two other channels. This type of valve is typically installed horizontally in pipelines. Depending on the driving method, ball valves are categorized into pneumatic, electric, and manual types.
● Compact Structure: With low flow resistance, can operate efficiently within the fluid control system range, thus minimizing energy loss.
● Easy to Operate: The switch adopts a unique spherical design, which can achieve quick opening and closing. Just rotate 90 degrees to significantly improve work efficiency.
● Good Sealing Performance: Advanced sealing materials and structures are used to ensure reliable sealing under various working conditions and prevent fluid leakage.
| DN(mm) | Dimension(mm) | |||||||
| G | A | D | K | H | C | 1 | n-d | |
| 15 | 85 | 35 | 95 | 65 | 45 | 14 | 2 | 4-414 |
| 20 | 90 | 38 | 105 | 75 | 55 | 16 | 2 | 4-414 |
| 25 | 99 | 50 | 115 | 85 | 65 | 16 | 2 | 4-414 |
| 32 | 122 | 60 | 135/140 | 100 | 78 | 18 | 2 | 4-φ18 |
| 40 | 127 | 68 | 145/150 | 110 | 85 | 18 | 3 | 4-418 |
| 50 | 135 | 108 | 160/165 | 125 | 100 | 20 | 3 | 4-418 |
| 65 | 146 | 112 | 180/185 | 145 | 120 | 20 | 3 | 4-418 |
| 80 | 175 | 122 | 195/200 | 160 | 135 | 20 | 3 | 8-418 |
| 100 | 185 | 153 | 215/220 | 180 | 155 | 22 | 3 | 8-φ18 |
| Type | Ball valve |
| Body Material | SS316/304,Carbon steel |
| Port Size | 1/4"~1" |
| Connection Size | MALE/FEMALE/TUBE FITTING |
| Work Preasure | 2000psi |
| Work Temperature | 50ºC~150ºC |
| Thread | NPT BSPP BSPT |
| Medium | Gas, Water, Oil |
Q1:What is a Three-Way Ball Valve?
It is a three-way ball valve is a valve with three passages and a spherical valve core.
Q2:Can the valve handle high-pressure applications?
Yes, the three-way ball valvee is specifically designed to handle high-pressure environments while ensuring reliable performance.
Our three-way ball valve is crafted from premium materials, ensuring exceptional durability and reliability. Its innovative design enables more precise and efficient fluid control, meeting the needs of a wide range of industrial applications. We offer comprehensive after-sales service to ensure that any issues encountered during use are promptly and effectively resolved. By choosing our three-way ball valve, you will enjoy superior product performance and a worry-free user experience.
