This valve is applicable as an on-off or pipelines with high-hardness grains or with both soft grains and corrosive media. Its nominal pressure is 1.6MPa, and applicable temperature below 200 Deg C.
All medium-contacting parts are made of structural ceramic, featuring extremely high chemical stability and hardness (Rockwell Hardness (HRC90), only next to diamond. Therefore, this valve has extremely strong resistance to abrasion, corrosion and erosion, good heat insulation and small thermal expansion.
The ball body is made with advanced grinding equipment and process, with high-precision ball roundness and good surface quality, and after facing-up with the valve seat, a good sealability can be obtained by means of self-lubrication of Zr02 Ceramic.
Thanks to the ceramic's strong resistance to abrasion, this valve is durable and extremely reliable, with a long service life being 2-4 times of that of Ti alloy and Monel Valves.
● Excellent Wear Resistance: Because the ball is made of ceramic material, the valve can still maintain good sealing performance under high speed fluid flushing, which prolongs its service life.
● Superior Sealing Performance: It can resist the erosion of a variety of chemical media, suitable for all kinds of harsh working conditions.
● Easy Operation: The valve is easy to operate and can be quickly switched through the electric actuator, which improves the work efficiency. At the same time, its compact structure and small volume make it easy to install and maintain.
| Sr.No. | Part | Material | Sr.No. | Part | Material |
| 1 | Valve Cover | WCB | 12 | Hex Nut | Grade 8 |
| 2 | Middle Body | WCB | 13 | Stud | B7 |
| 3 | Middle Body Sleeve | Ceramic | 14 | Packing Gland | WCB |
| 4 | O-Ring | PTFE | 15 | Spacer | Q235 |
| 5 | Flange Sleeve | Ceramic | 16 | Circlip for Shaft | 65Mn |
| 6 | Ball | Ceramic | 17 | Handle | CS |
| 7 | O-Ring | PTFE | 18 | Gasket | Q235 |
| 8 | Dish Spring | 50CrVA | 19 | Screw | 35# |
| 9 | Washer | 304 | 20 | Hex Bolts | B7 |
| 10 | Stem | 2Cr13 | 21 | Big Washer | PTFE |
| 11 | Packing | PTFE | 22 | Seat | Ceramic |
| Nominal Diameter | 1/2"-8" |
| Nominal pressure | Class 150 ~ 600 LB |
| Temperature | -20ºC~250ºC |
| Connecting type | flange , wafer |
| Material | SS, CS |
| Driving means | manual, pneumatic, wore gear, electric |
| Applicable medium | Heavy oil , glue and other easy-clotting medium |
Q1:What is the main suitable of this valve?
This product is especially suitable for steel, aluminum, fiber, small solid particles, pulp, coal ash, petroleum gas and other media.
Q2:What mechanical principle is used?
Electric actuators convert electric signals into mechanical power to drive the valve stem rotation. The valve stem is tightly connected to a ceramic ball, which rotates when the valve stem turns, thereby changing the valve's on-off state. The ceramic ball has extremely high hardness and wear resistance, effectively resisting the erosion and corrosion of media, ensuring long-term stable operation of the valve. Additionally, electric actuators offer advantages such as compact structure, rapid response, and precise control, making electric ceramic ball valves widely used in industrial automation control systems.
Our electric ceramic ball valves are made from high-quality ceramic materials, ensuring excellent sealing performance even under high-speed fluid erosion, effectively extending their service life. Their superior corrosion resistance can withstand the erosion of various chemical media, making them suitable for harsh working environments. We pay attention to detailed design to ensure the stability and reliability of the valve, providing users with a worry-free experience. By choosing our electric ceramic ball valves, you will receive an efficient, durable, and reliable fluid control solution.
