Suitable for switches or pipes handling hard or soft particles and corrosive fluids. It can withstand a nominal pressure of up to 1.6 megapascals and temperatures as high as 200 degrees Celsius. All components in contact with the medium are made of structural ceramic materials, which have extremely stable chemical properties and high hardness (Rockwell hardness HRC90, second only to diamond). Therefore, these valves exhibit excellent wear resistance, corrosion resistance, and erosion resistance, along with superior insulation performance and minimal thermal expansion. The ball section is manufactured using advanced grinding techniques and equipment to ensure high roundness and a smooth surface. After precise mating with the valve seat, excellent sealing performance is achieved through self-lubricating zirconia ceramics. Due to the excellent wear resistance of ceramics, this valve is very durable and reliable, with a service life two to four times that of titanium alloy and Monel alloy valves.
● Excellent Wear Resistance: The ball is made of ceramic material, and even under the erosion of high-speed fluids, the valve can maintain excellent sealing effect, thereby improving its service life.
● Superior Sealing Performance: Can resist corrosion from various chemicals and is suitable for various harsh working conditions.
● Easy Operation: The valve is easy to operate, the electric actuator switches quickly, which improves the work efficiency. In addition, the structure is compact, small in size, and easy to install and maintain.
| Sr.No. | Part | Material | Sr.No. | Part | Material |
| 1 | Valve Cover | WCB | 12 | Hex Nut | Grade 8 |
| 2 | Middle Body | WCB | 13 | Stud | B7 |
| 3 | Middle Body Sleeve | Ceramic | 14 | Packing Gland | WCB |
| 4 | O-Ring | PTFE | 15 | Spacer | Q235 |
| 5 | Flange Sleeve | Ceramic | 16 | Circlip for Shaft | 65Mn |
| 6 | Ball | Ceramic | 17 | Handle | CS |
| 7 | O-Ring | PTFE | 18 | Gasket | Q235 |
| 8 | Dish Spring | 50CrVA | 19 | Screw | 35# |
| 9 | Washer | 304 | 20 | Hex Bolts | B7 |
| 10 | Stem | 2Cr13 | 21 | Big Washer | PTFE |
| 11 | Packing | PTFE | 22 | Seat | Ceramic |
| Nominal Diameter | 1/2"-8" |
| Nominal pressure | Class 150 ~ 600 LB |
| Temperature | -20ºC~250ºC |
| Connecting type | flange , wafer |
| Material | SS, CS |
| Driving means | manual, pneumatic, wore gear, electric |
| Applicable medium | Heavy oil , glue and other easy-clotting medium |
Q1:What is the main suitable of this valve?
This product is especially suitable for steel, aluminum, fiber, small solid particles, pulp, coal ash, petroleum gas and other media.
Q2:What mechanical principle is used?
The electric actuator converts electrical signals into mechanical energy, driving the valve stem to rotate. The valve stem is tightly integrated with the ceramic ball; when the valve stem rotates, the ceramic ball also rotates, thus adjusting the opening and closing state of the valve. The ceramic ball is extremely hard and wear-resistant, effectively resisting media erosion and corrosion, ensuring long-term stable operation of the valve. In addition, the electric actuator has a compact structure, rapid response, and precise control, making the electric ceramic ball valve widely used in industrial automation control systems.
Choose our high-quality electroceramic ball valve, and you will experience the superior performance brought by premium ceramic materials. Even under the erosion of high-speed fluids, it can maintain excellent sealing effects, significantly extending its service life. It boasts outstanding corrosion resistance, capable of withstanding the erosion of various chemicals, making it suitable for harsh working environments. We have meticulously designed to ensure the stability and reliability of the valve, providing you with a worry-free operating experience. Choose our electroceramic ball valve, and you will obtain an efficient, durable, and reliable fluid control solution.
